Vespa PX125-150 LML Sprint Super Cosa Malossi Sport Racing Alloy 177cc Cylinder Kit

Product Code: BD15077

Save 10%
£408.81
£367.93

Delivery Information

We're pleased to offer FREE UK Delivery on orders placed over £100.00.

Delivery is available Worldwide. See our Delivery Information page for further details.

Returns & Refunds

We're committed to providing a great customer service and wish our customers to be 100% satisfied with purchases.

Please review our Returns Information or Contact Us if you have any queries.

Payment Security

All our orders are 100% secure. We know this because our e-commerce system is Level 1 PCI compliant and uses 128 bit SSL encryption to ensure credit card data is secure.

Which is the same level of encryption used by large banks around the world.



Malossi has extended its cylinder range for the Vespa large-frame 125-150cc engines (Sprint, PX, Cosa, LML) with the three cylinder variants Sport 177ccm, MHR 177ccm and MHR 187ccm.

They are completely redesigned and have nothing to do with their predecessor made of grey cast iron and only 166ccm. The aluminium used as cylinder material makes the kit thermally more stable than the 166ccm cylinder and now allows a Ø63mm bore. Externally the cylinders are almost identical. All three versions use the same cylinder head and the same piston (the sport kit uses a two ring piston). The formerly patented CVF II system is no more used, Malossi now favors much bigger transfer port inlets. An adaptation to the engine housing is therefore obligatory for full power/torque.

MALOSSI 177 SPORT
The Sport cylinder is aimed at users who want to use their engine on a daily basis and therefore do not attach great importance to extreme peak performance and revs. Malossi therefore uses tame steering angles that allow the cylinder to be used early in the rev range. The large transfer surfaces as well as the small one-piece exhaust window (compared to the big double MHR exhaust port) allow a good and high torque with a sufficiently large speed range.

  • StrokexBore: 57xØ63mm
  • displacement: 177,59cm³
  • Exhaust: 173,5°.
  • Transfer: 115.5°.
  • Blowdown: 29°.
  • Squish: 1.0mm (piston is 0.5mm back at top dead center)
  • Compression ratio: 1:10.8
  • Number of transfer ports: 7
  • Piston rings: 2
  • Ignition timing: 18° b.t.d.c.


Fitment

LML STAR DELUXE / STELLA 125 and 150
VESPA 150 SPRINT Veloce / TS125 - FOR 3 PORT MOTORS ONLY
VESPA COSA 125
VESPA P 125 X
VESPA P 150 X
VESPA PX 125 E
VESPA PX 125 E DISC
VESPA PX 125 EFL
VESPA PX 150 E
